Enameled Square Aluminum Wire

Enamelled square aluminum wire available size Thickness(Width)/a (b): 1.2-9.1mm

Request Our Latest Price

Insulation Layer

Single-layer, double-layer

Thermal class

180℃, 200℃, 220℃, 240℃

Dimension

Thickness(Width)/a (b): 1.2-9.1mm

Application

used for transformer; generator; refrigeration System, Class C generators, UPS power supply, electronic transformer etc.

OVERVIEW

Enameled Square Aluminum Wire Description

Enamelled square aluminum wire available size Thickness(Width)/a (b): 1.2-9.1mm

180 grade polyesterimide / polyamide enameled square aluminum wire
200 grade modified polyesterimide enameled square aluminum wire
200 grade polyamideimide enameled square aluminum wire
220 grade polyesterimide enameled square aluminum wire

More details show

CORE FEATURES

Power Transformer loll and dryl, Traction Motor &Transformer (Generator, Electromotor) and windings for all kinds of electric appliance

Ensure that the wire can operate safely at high temperatures without significant degradation.

Prompt Reply Within 12 Hours.

The enamel insulation provides excellent dielectric strength and reliability.

Good electrical properties and Lightweight.

Provide advantages in packing density and allows for a more efficient use of available space in winding applications.

Aluminum is a cost-effective alternative to copper wire.

Make it easier to wind and fit into tight spaces.

prevent short circuits and improve the overall electrical performance of the device.

If you are interested in our products, you can contact us in the following ways.

Request Our Latest Price

Product Parameters

AWG SWG MM ENAMELED SQUARE ALUMINUM WIRE

LP Industry factory can produce enameled square aluminum wires directly and offers a wide range of products : thickness(width)/a(b)1.2~9.1mm.

Enamelled Wire - Diameters

For enameled square aluminum wire: thickness(width)/a(b)1.2~9.1mm
For other metals: Please inquire

Specifications for Enamelled Wire

LP produces enamelled wires according to many different specifications. The most important worldwide used specification is IEC, besides NEMA in North America and JIS in Asia.

Download the Data Sheet

Conductor	Aluminum Wire
Dimension	Aluminum:Thickness(width)/a(b)1.2~9.1mm
Thermal Class(℃）	180（Class H)；200(Class C);220(Class C +); 240(Class HC)
Insulation thickness	Single, Heavy
Certificate	UL
Standard	IEC, NEMA, GB, JIS
Packing	30kg-150kg ply-wood spool(250400/250500/250600/250730)
Application	Transformer;generator;refrigeration System Class C generators UPS power supply，electronic transformer etc.

Product Packaging

Plastic spool or wooden spool, flat wire length are customizable;

The usual spool specifications :

PT-4, PT-10,PT-25,PT-30,PT-60,PT-90,PT-200 or according to customer requirement

About The Packing, We Can According To Customers’ Requirement!

Enameled Wire Production Process

All enamelled wires are enamelled on special enamelling machines which are developed and produced by LP for our exclusive use. Enamelling of enamelled wire is a continuous process, mainly consisting of the annealing process, enamel application, curing process, lubricant application, tension control and spooling.

Annealing Process

During the drawing process the bare wire’s grain structure has been changed through cold deformation. Annealing will re-crystalize the copper and make it
